BGC Innova™ Duragrid™
Product Description
BGC Innova™ Duragrid™ Facade System is a cavity based, express jointed wall cladding system. It is designed to be used as an external cladding system for residential and light commercial buildings.
It is a cost effective cladding that offers design choice and is ideally suited to be used in conjunction with BGC Nuline and other BGC Claddings.
BGC Innova Duragrid is a fully sealed Fibre Cement sheet with a high quality UV cured primer/sealer on the face and edges and back sealed.
Features:
- Lightweight and highly durable
- Unique back flashing to speed construction
- Can be screwed, nailed or brad fixed in all wind zones up to Extra high ( NZS3604:2011)
- Definitive negative detail as only minimal sealant required in the vertical joint
- Constructed with a structural timber batten
Available in 1190, 2390 and 2990 x 1190 sheets
