MAXRaft Plus+ TC2, PILES OR EXPANSIVE SOILS
Product Description
MAXRaft Plus+ is designed to meet the requirements of the upcoming building code changes where embedded underfloor heating is specified and the slab is being built on less stable ground such as TC2, expansive soils, 200KPA or piled sites.
Typically the slab is either 320/340 or 400/420mm in height, however this can be adjusted to meet site specific requirements.
The perimeter insulation, ribs and load bearing insulation from a standard MAXRaft® remain the same, however the SOLID PODS in the slab have increased thermal performance over traditional waffle pods to increase the R-value of the slab.
Each of these components combine to give a foundation with an R value between 2.5 and 4.03 depending on the design.
MAXRaft Plus+ meets the requirements of Homestar V5 and can be adjusted to meet the requirements of Passive House Certification if required.
Key Features
- Solid insulation throughout
- Easily meets the building code
- Suitable with 90mm/140mm/SIPS
- VH EPS perimeter & thickening insulation
- Panel plan and pre-cut materials including PODS
- Minimum waste / Recycled polystyrene materials
- 50/50 recycled pods or S grade solid pods
