Titan™ Facade Panel
排列方式 James Hardie
产品说明
Titan™Facade Panel是一种用于商业和住宅项目的外部覆层。提供表达联合功能。适用于外墙，面板和拱肩。实现大胆的几何设计。
产品简介：
9毫米厚
2400,2700或3000mm长
宽1190mm
主要特征：
中密度板材，背面密封，具有额外的防潮性能
片材经过预涂和打磨，为涂料提供稳定的基础
根据当前的James Hardie Fire and Acoustic Design Manual安装时，可以实现60分钟防火系统
Titan Facade Panel在正确安装和维护时可防火，防潮和腐烂
董事会保修15年
欲了解更多信息，请访问http://www.jameshardie.co.nz/
