GreenUp highbay gen2

Product Description

GreenUp Highbay BY550 is a high efficient and reliable LED highbay for industrial high-ceiling facilities without humid and dusty requirement, designed for both new project and retrofit. This lighting system can deliver up to 88% energy savings with the integrated G2 Actimlume Wireless. It delivers point to point replace up to 400W HID and T5 6x54W higbay with easy installation. There are three beam shapes to choose with good light quality CRI85 and UGR 17. Integrated with G2 Actilume Wireless, GreenUp BY550 provide connected lighting with daylight, occupancy sensor, and ZigBee wireless communication will increase your savings by upgrading to an intelligent system and delivering a one-stop solution for your Factory, Warehouse, Distribution center, Indoor spot hall, and other high ceiling indoor application.



  • System wattage: 75W120W153W
  • System lumen: 10,500lm16,000lm21,000lm
  • Power factor: 0.95
  • Correlated color temperature: CCT4000K (NW), 6500K (CW)
  • CRI >Ra80
  • SDCM <5
  • Beam Angle/ Distribution: Wide Beam (WB): 2x45°, Narrow Beam (NB): 2x30°, High Rack Optics (HRO): 45°x90°
  • Operating Temperature :  45°C
  • Lifetime: 65,000 hours (L70)*
  • Driver/ Systems: Fixed (PSU), DALI with Coded light (PSDVLC), Actilume Wireless (ACW)
  • IP rating: IP40
  • Electrical Class: Class I
  • IK rating: IK03
  • Input Voltage : 220V240V,
  • Input frequency: 50/60Hz
  • Installation Mounting Type: Surface mounted**, Pipe mounted** and Suspended (suspension set included in box)
  • Housing colour: White powder coated (RAL9003)
  • Material Housing: Aluminium Extrusion
  • Type: BY560
  • Equivalent of HPIP 250W TL5 4X54WHPIP 400W TL5 6X54W
