Coreline Wall-mounted Ceiling surface mounted

Product Description

CoreLine Wall-mounted is a circular-shaped surface-mounted luminaire that is easy to apply in circulation areas such as hallways and staircases. The modern unobtrusive design, in combination with its homogeneous light distribution it delivers, ensures that this luminaire blends into most building architectures. With the push-in connectors, installation is fast and straightforward.



  • Light source: Non-replaceable LED module
  • Power:  (+/-10%) 12 W (LED12S version), 22 W (LED20S version and 36 W (LED34S version)
  • Beam angle: 120º
  • Luminous flux: 1200 lm (LED12S version), 2000 lm (LED20S version) and 3400 lm (LED34S version)
  • Correlated Color Temperature: 3000 or 4000 K
  • Color Rendering Index ≥ 80
  • Median useful life L70B50 50,000 hours
  • Median useful life L80B50 38,000 hours
  • Median useful life L90B50 18,000 hours
  • Average ambient temperature: +25 ºC
  • Operating temperature range -20 to +35 ºC (wall-mounted position), -20 to +25 ºC (ceiling-mounted position) and 0 to +25 ºC (emergency lighting)
  • Driver: Built-in, replaceable
  • Mains voltage: 220-240V / 50-60 Hz
  • Dimming: Non-dimmable (PSU versions) and Dimmable (PSR and DALI versions),
  • Options:  Emergency lighting (integrated): 3 hours (EL3), Movement detection unit (integrated): on/off switch with day
  • light override including grouping functionality (MDU) and DALI driver and movement detection unit (integrated)
  • Material Housing: Polyamide
  • Diffuser: high grade polycarbonate, UV resistant
  • Color: White (RAL 9003)
  • Optical cover: Polycarbonate diffuser
  • Connection: Push-in connector
  • Maintenance: LED module closed, no internal cleaning required
  • Installation: Screw mounting, directly onto surface, 4-point screw installation of housing to wall, Twist lock connection diffuser to housing, Through-wiring possible
  • Type: WL130V (slim version) and WL131V (deeper version)
