LCN 6030 Series Concealed Transom Closer

Product Description

The LCN 6030 series is a heavy duty non-handed, fixed strength, double acting, concealed closer designed to fit in a narrow 44mm aluminium transom. The track arm and roller assembly, provide smooth, quiet door control. The closer cylinder is fitted in the aluminium frame, with the track fitted in the top rail of the door, providing complete concealment of the closer and its arm. The LCN 6030 series has designed to be used on metal or timber swinging commercial exterior and interior doors and is ideally suited for institutional or heavy usage double acting doors. It is recommended that IVES 7253 center pivots be used in conjunction with LCN 6030 series closers.

Application: Commercial

General Specifications:
Handing: Non-handed
Strength: Fixed Strength 3 or 4
Arm Type: Single Lever Arm (Floor pivot separate)
Regulating Controls: Closing Speed, Latching Speed and Backcheck
Body Material: Cast Iron
Mounting: Body Concealed in Transom

Warranty: 10 Years

- Hold Open

Available Finishes:
- Aluminium
