A Series 132 - Partitioning System
Product Description
A Series 132 Aluminium Partition provides a central line glazing with numerous configurations and design options offering a complete partition system for plasterboard and glazing.
A Series 132 has the following features:
- Standard profile size of 132mm x 25mm or 132mm x 50mm
- Standard wall size based around 92mm steel stud with one layer of plaster board up to two layers on each side
- Can also achieve 150mm stud with one layer each side
- Can accommodate glass thicknesses between 6mm - 12.38mm
- Door thicknesses between 38mm - 50mm can be used
- Shadowline details optional
All our aluminium partition suites carry the Declare label.
Final Assembly: New Zealand. Life Expectancy: 50+ years.
End of of Life Options: 100% Reusable/Recyclable.
