Vertical Shiplap Weatherboards

Product Description

Vertical Shiplap complements all architectural styles from stark bold minimalism, to classical period styling, or simple clean and modern lines to fit a stunning coastal setting.

Hermpac offer quality Vertical Shiplap Weatherboards in a wide range of standard profiles. These popular 'off the shelf' profiles offer great creative scope.

Where a more unique solution is required, the extensive Hermpac Custom Design range gives designers and specifiers an extra freedom to meet individual needs.

For design peace of mind, Hermpac's VertiLine Vertical Shiplap Cavity System is a BRANZ Appraised and Codemark solution for vertical shiplap weatherboards and covers our wide range of both standard and custom designed profiles.

Weatherboard Calculator

Standard Profiles (Over Cavity or Direct Fixed)

HP50
115mm Cover, 18.5mm Thick
HP51
110mm Cover, 18.5mm Thick
12.5mm Negative Detail
HP52
155mm Cover, 18.5mm Thick
12.5mm Negative Detail
HP53
110mm Cover, 18.5mm Thick
12.5mm Negative Detail
HP54
155mm Cover, 18.5mm Thick
12.5mm Negative Detail
HP55
110mm Cover, 18.5mm Thick
7mm Negative Detail
HP56
155mm Cover, 18.5mm Thick
7mm Negative Detail
HP57
155mm Cover, 18.5mm Thick
12.5mm Negative Detail
HP58
110mm Cover, 18.5mm Thick
7mm Negative Detail
HP59
155mm Cover, 18.5mm Thick
7mm Negative Detail
HP60
155mm Cover, 18.5mm Thick
7mm Negative Detail
CP862
65mm Cover, 18.5mm Thick
6mm Negative Detail
CP1470
165mm Cover, 18.5mm Thick
10mm Negative Detail
CP1739
115mm Cover, 18.5mm Thick
6mm Negative Detail
CP1740
165mm Cover, 18.5mm Thick
6mm Negative Detail
CP1741
65mm Cover, 28mm Thick
6mm Negative Detail
CP1742
115mm Cover, 28mm Thick
6mm Negative Detail
CP1743
165mm Cover, 28mm Thick
6mm Negative Detail
CP2257
65mm Cover, 18.5mm Thick
10mm Negative Detail
CP2258
115mm Cover, 18.5mm Thick
10mm Negative Detail
CP2498
205mm Cover, 28mm Thick
6mm Negative Detail




For more Hermpac Vertical Shiplap profiles refer to the Hermpac website or email [email protected]
