Name: Terra Lana Chatterblock+ Acoustic Interior Insulation
Brand: Terra Lana

Back

Product Description

CHATTERBLOCK+^® Acoustic Insulation provides a strong sound barrier between walls, midfloor and outside, thanks to wool's remarkable sound dampening qualities and high density of at least 18kg/m3. It is also an excellent thermal insulator.

Terra Lana CHATTERBLOCK+^® Acoustic Insulation can be substituted within all GIB noise control systems (including inter-tenancy walls).

Applications

Intertenancy walls and floors
Residential and commercial buildings
Absorber behind perforated ceiling systems
Internal walls between living areas, bedrooms and midfloor.

Acoustic test reports

CHATTERBLOCK+® has been assessed for its acoustic performance by Marshall Day Acoustics.

Marshall Day Acoustics generally recommend a flow resistance of 140-200 Rayls or greater, for an acoustic insulation product to be used with double stud or similar wall construction

CHATTERBLOCK+ Acoustic Wall Insulation

R VALUE	THICKNESS	CODE
R 2.2	90mm	22.90.560
R 2.4	90mm	24.90.560
R 3.2	140mm	32.140.560

CHATTERBLOCK+^® Acoustic Wall Insulation is available is widths of 360mm and 560mm. It is the same composition as our external wall insulation so it is dense (at least 18kg/m3), rigid and will friction fit within the wall framing.

Acoustic test reportsCHATTERBLOCK+® has been assessed for its acoustic performance by Marshall Day Acoustics.

Marshall Day Acoustics generally recommend a flow resistance of 140-200 Rayls or greater, for an acoustic insulation product to be used with double stud or similar wall construction

CHATTERBLOCK+ Acoustic Midfloor Insulation

R VALUE	THICKNESS	CODE
R2.2	90mm	22.90.415
R3.2	140mm	32.140.415

Our mid floor insulation should be ordered specifically to fit between the mid floor joist spacing. Allow 15mm wider than the inside measurement between joists for the product to friction fit. There is no extra cost to cut specific widths providing there is more than 50m2 ordered per width.

Acoustic test reports

CHATTERBLOCK+® has been assessed for its acoustic performance by Marshall Day Acoustics.

Marshall Day Acoustics generally recommend a flow resistance of 140-200 Rayls or greater, for an acoustic insulation product to be used with double stud or similar wall construction
