Grooved Ply
Product Description
Grooved Radiata Pine is manufactured from selected Pine veneer. The veneer is rotary cut.
It meets the NZ building code, and is from renewable plantations. The clear face appearance grade makes this very popular in cabinetry and lining ply alike.
Grooves are 100mm centres but other options can be custom done on request.
Uses:
- Residential wall and ceilings
- Commercial and classroom linings
- Shop Fittings
- Joinery
- Garage and Sleep out linings
Specifications
|
Code |
Size |
Thickness |
Info |
Grade |
|
E2000-P |
2400 x 1200 |
7.5mm |
Square Edge |
CD+ |
|
E2000 |
2400 x 1200 |
7.5mm |
Square Edge |
SD |
|
E2000-T |
2400 x 1200 |
7.5mm |
Square Edge |
SD LOSP |
|
E2005-P |
2400 x 1200 |
9mm |
Square Edge |
CD+ |
|
E2005 |
2400 x 1200 |
9mm |
Square Edge |
SD |
|
E2005-T |
2400 x 1200 |
9mm |
Square Edge |
SD LOSP |
|
E2010-P |
2400 x 1200 |
12mm |
T&G |
CD+ |
|
E2010 |
2400 x 1200 |
12mm |
T&G |
SD |
|
E2010-T |
2400 x 1200 |
12mm |
T&G |
SD LOSP |
|
E22015 |
2700 X 1200 |
12mm |
T&G |
SD |
Plywood is a natural product that can be affected by changes in weather conditions: moisture and temperature. Increased moisture content temperature variation may cause internal stresses causing previously flat sheets to bow. At Summitply, precautions are taken to minimize this effect.
However, once the plywood has left our warehouse we cannot guarantee sheets to remain flat unless fastened. This is particularly important with pine ply (as it is a softwood),where free standing kitchen/cabinet doors are concerned. When storing panels, stack on a firm raised base with enough support to prevent sagging.
Cover the pallet to protect top and edges.
